FLUKE 9144 多功能計量爐
名稱：過程校準儀
品牌：
型號：
簡介：FLUKE 9144 多功能計量爐擁有最新的技術，除了沿用917X系列上的雙段控溫技術使得914X計量爐垂直均勻性達到 0.05℃之外，它還采用了更新的控制器，在控制爐溫升降和保持時改善了穩定性的控制。并且能對電源電壓進行補償，使計量爐運行...
申請服務
- 產品介紹
FLUKE 9144 多功能計量爐擁有最新的技術，除了沿用917X系列上的雙段控溫技術使得914X計量爐垂直均勻性達到 ±0.05℃之外，它還采用了更新的控制器，在控制爐溫升降和保持時改善了穩定性的控制。并且能對電源電壓進行補償，使計量爐運行時更穩定，不受外界電源波動的干擾。FLUKE 9144 多功能計量爐最適合工業現場，現場計量爐是專門針對工業過程環境設計的。其重量不足8.2 kg，體積小，使其非常容易搬運。現場計量爐特別優化了速度性能，可以在15分鐘內降溫至-25 °，以及在15分鐘內加熱至660 ℃。這樣的功能為您的現場計量節省了大量的寶貴時間，其帶來的經濟效益顯而易見。福祿克 9144 多功能計量爐具有最多樣化的功能。FLUKE 9144 多功能計量爐擁有最全面的現場解決方案。以下是艾克賽普為您介紹FLUKE 9144 多功能計量爐的技術指標及配件，如有相關問題，歡迎咨詢，0731-84284278 84284378。
| 9142 | 9143 | 9144 | |
| 23℃下的溫度范圍 | -25℃～150℃ | 33℃～350℃ | 50℃～660℃ |
| 顯示準確度 | ±0.2℃，全溫范圍 | ±0.2℃，全溫范圍 | ±0.35℃ @50℃ |
| ±0.35℃@ 420℃ | |||
| ±0.5℃ @660℃ | |||
| 穩定性 | ± 0.01℃，全溫范圍 | ± 0.02℃ @ 33℃ | ± 0.03℃ @ 50℃ |
| ± 0.02℃ @ 200℃ | ± 0.05℃ @ 420℃ | ||
| ± 0.05℃ @ 660℃ | |||
| 40 mm內的軸向均勻性 | ± 0.05℃，全溫范圍 | ± 0.04℃ @ 33℃ | ± 0.05℃ @ 50℃ |
| ± 0.1℃ @ 200℃ | ± 0.35℃ @ 420℃ | ||
| ± 0.2℃ @ 350℃ | ± 0.5℃ @ 660℃ | ||
| 徑向均勻性 | ± 0.01℃，全溫范圍 | ± 0.01℃ @ 33℃ | ± 0.02℃ @ 50℃ |
| ± 0.015℃ @ 200℃ | ± 0.05℃ @ 420℃ | ||
| ± 0.02℃ @ 350℃ | ± 0.1℃ @ 660℃ | ||
| 負載影響（使用一支6.35 mm的參考探頭和3支6.35 mm的被測探頭） | ±0.006℃，全溫范圍 | ± 0.015℃，全溫范圍 | ± 0.015℃ @ 50℃ |
| ± 0.025℃ @ 420℃ | |||
| ± 0.035℃ @ 660℃ | |||
| 遲滯 | 0.025 | 0.03 | 0.1 |
| 工作條件 | 0℃～50℃，0 %～90 % RH（無凝結） | ||
| 環境條件（滿足溫度范圍之外的所有技術指標） | 13℃～33℃ | ||
| 插入深度（井深） | 150 mm | ||
| 插塊直徑 | 30 mm | 25.3 mm | 24.4 mm |
| 升溫時間 | 16分鐘：23℃～140℃ | 5 分鐘：33℃～350℃ | 15 分鐘：50℃～660℃ |
| 23 分鐘：23℃～150℃ | |||
| 25分鐘：-25℃ ～150℃ | |||
| 降溫時間 | 15分鐘：23℃～-25℃ | 32分鐘：350℃～33℃ | 35分鐘：660℃～50℃ |
| 25分鐘：150℃～-23℃ | 14分鐘：350℃～100℃ | 25分鐘：660℃～100℃ | |
| 分辨率 | 0.01° | ||
| 顯示 | LCD，℃ 或 °F 用戶可選 | ||
| 尺寸（高 x 寬 x 深） | 290 mm×185 mm×295 mm | ||
| 重量 | 8.16 kg | 7.3 kg | 7.7 kg |
| 電源要求 | 110V－115V(± 10 %)，50/60 Hz，635 W | 110V－115V(± 10 %)，50/60 Hz，1400 W | |
| 230 V (± 10 %)，50/60Hz，575 W | 230 V（± 10 %），50/60 Hz，1800 W | ||
| 計算機接口 | 包括RS-232和9930 Interface-it 控制軟件 | ||
| 型號 | 描述 | |
| 9142-X | 現場計量井，–25 °C 到 150 °C，w/9142-INSX | |
| 以上型號中的 X 將替換為 A、B、C、D、E 或 F，代表適當的嵌板。 | ||
| 配件 | 描述 | |
| 9142-INSA | A 型插塊，英制各種插孔 | |
| 9142-INSB | B 型插塊，英制對稱插孔 | |
| 9142-INSC | C 型插塊，0.25 英寸插孔 | |
| 9142-INSD | D 型插塊，公制對稱插孔 | |
| 9142-INSE | E 型插塊，公制插孔和0.25 英寸插孔 | |
| 9142-INSF | F 型插塊，公制對稱插孔和0.25 英寸插孔 | |
| 9142-INSZ | Z 型插塊，空白插塊 | |
| G3P9142-STD | Three-year Gold CarePlan with annual standard calibration, Instrument covered: 9142, FIELD METROLOGY WELL | |
| G5P9142-STD | Five-year Gold CarePlan with annual standard calibration, Instrument covered: 9142, FIELD METROLOGY WELL | |
| GCP9142-STD | One-year Gold CarePlan with annual standard calibration, Instrument covered: 9142 Field Metrology Well | |
| S3P9142-STD | Three-year Silver CarePlan with annual standard calibration, Instrument covered: 9142, FIELD METROLOGY WELL | |
| S5P9142-STD | Five-year Silver CarePlan with annual standard calibration, Instrument covered: 9142, FIELD METROLOGY WELL | |
| SCP9142-STD | One-year Silver CarePlan with annual standard calibration, Instrument covered: 9142, FIELD METROLOGY WELL | |
| 9142-X-P | 現場計量井，–25 °C 到 150 °C，w/9142-INSX，w/電子工藝 | |
| 以上型號中的 X 將替換為 A、B、C、D、E 或 F，代表適當的嵌板。 | ||
| 配件 | 描述 | |
| 9142-INSA | A 型插塊，英制各種插孔 | |
| 9142-INSB | B 型插塊，英制對稱插孔 | |
| 9142-INSC | C 型插塊，0.25 英寸插孔 | |
| 9142-INSD | D 型插塊，公制對稱插孔 | |
| 9142-INSE | E 型插塊，公制插孔和0.25 英寸插孔 | |
| 9142-INSF | F 型插塊，公制對稱插孔和0.25 英寸插孔 | |
| 9142-INSZ | Z 型插塊，空白插塊 | |
| G3P9142P-STD | Three-year Gold CarePlan with annual standard calibration, Instrument covered: 9142-P, FIELD METROLOGY WELL | |
| G5P9142P-STD | Five-year Gold CarePlan with annual standard calibration, Instrument covered: 9142-P, FIELD METROLOGY WELL | |
| GCP9142P-STD | One-year Gold CarePlan with annual standard calibration, Instrument covered: 9142-P, FIELD METROLOGY WELL | |
| S3P9142P-STD | Three-year Silver CarePlan with annual standard calibration, Instrument covered: 9142-P, FIELD METROLOGY WELL | |
| S5P9142P-STD | Five-year Silver CarePlan with annual standard calibration, Instrument covered: 9142-P, FIELD METROLOGY WELL | |
| SCP9142P-STD | One-year Silver CarePlan with annual standard calibration, Instrument covered: 9142-P, FIELD METROLOGY WELL | |
| 9143-X | 現場計量井，33 °C 到 350 °C，w/9143-INSX | |
| 以上型號中的 X 將替換為 A、B、C、D、E 或 F，代表適當的嵌板。 | ||
| 配件 | 描述 | |
| 9143-INSA | A 型插塊，英制各種插孔 | |
| 9143-INSB | B 型插塊，英制對稱插孔 | |
| 9143-INSC | C 型插塊，0.25 英寸插孔 | |
| 9143-INSD | D 型插塊，公制對稱插孔 | |
| 9143-INSE | E 型插塊，公制各種插孔和0.25 英寸插孔 | |
| 9143-INSF | F 型插孔，公制對稱插孔和0.25 英寸插孔 | |
| 9143-INSZ | Z 型插孔，空白插塊 | |
| G3P9143-STD | Three-year Gold CarePlan with annual standard calibration, Instrument covered: 9143, FIELD METROLOGY WELL | |
| G5P9143-STD | Five-year Gold CarePlan with annual standard calibration, Instrument covered: 9143, FIELD METROLOGY WELL | |
| GCP9143-STD | One-year Gold CarePlan with annual standard calibration, Instrument covered: 9143, FIELD METROLOGY WELL | |
| S3P9143-STD | Three-year Silver CarePlan with annual standard calibration, Instrument covered: 9143, FIELD METROLOGY WELL | |
| S5P9143-STD | Five-year Silver CarePlan with annual standard calibration, Instrument covered: 9143, FIELD METROLOGY WELL | |
| SCP9143-STD | One-year Silver CarePlan with annual standard calibration, Instrument covered: 9143, FIELD METROLOGY WELL | |
| 9143-X-P | 現場計量井，33 °C 到 350 °C，w/9143-INSX，w/電子工藝 | |
| 以上型號中的 X 將替換為 A、B、C、D、E 或 F，代表適當的嵌板。 | ||
| 配件 | 描述 | |
| 9143-INSA | A 型插塊，英制各種插孔 | |
| 9143-INSB | B 型插塊，英制對稱插孔 | |
| 9143-INSC | C 型插塊，0.25 英寸插孔 | |
| 9143-INSD | D 型插塊，公制對稱插孔 | |
| 9143-INSE | E 型插塊，公制各種插孔和0.25 英寸插孔 | |
| 9143-INSF | F 型插孔，公制對稱插孔和0.25 英寸插孔 | |
| 9143-INSZ | Z 型插孔，空白插塊 | |
| G3P9143P-STD | Three-year Gold CarePlan with annual standard calibration, Instrument covered: 9143-P, FIELD METROLOGY WELL | |
| G5P9143P-STD | Five-year Gold CarePlan with annual standard calibration, Instrument covered: 9143-P, FIELD METROLOGY WELL | |
| GCP9143P-STD | One-year Gold Careplan with annual standard calibration, Instrument covered: 9143-P, FIELD METROLOGY WELL | |
| S3P9143P-STD | Three-year Silver CarePlan with annual standard calibration, Instrument covered: 9143-P, FIELD METROLOGY WELL | |
| S5P9143P-STD | Five-year Silver CarePlan with annual standard calibration, Instrument covered: 9143-P, FIELD METROLOGY WELL | |
| SCP9143P-STD | One-year Silver CarePlan with annual standard calibration, Instrument covered: 9143-P, FIELD METROLOGY WELL | |
| 9144-X | 現場計量井，50 °C 到 660 °C，w/9144-INSX | |
| 以上型號中的 X 將替換為 A、B、C、D、E 或 F，代表適當的嵌板。 | ||
| 配件 | 描述 | |
| 9144-INSA | A 型插塊，英制各種插孔 | |
| 9144-INSB | B 型插塊，英制對稱插孔 | |
| 9144-INSC | C 型插塊，0.25 英寸插孔 | |
| 9144-INSD | D 型插塊，公制對稱插孔 | |
| 9144-INSE | E 型插塊，公制各種插孔和0.25 英寸插孔 | |
| 9144-INSF | F 型插塊，公制對稱插孔和0.25 英寸插孔 | |
| 9144-INSZ | Z 型插孔，空白插塊 | |
| G3P9144-STD | Three-year Gold CarePlan with annual standard calibration, Instrument covered: 9144, FIELD METROLOGY WELL | |
| G5P9144-STD | Five-year Gold CarePlan with annual standard calibration, Instrument covered: 9144, FIELD METROLOGY WELL | |
| GCP9144-STD | One-year Gold Careplan with annual standard calibration, Instrument covered: 9144, FIELD METROLOGY WELL | |
| S3P9144-STD | Three-year Silver CarePlan with annual standard calibration, Instrument covered: 9144, FIELD METROLOGY WELL | |
| S5P9144-STD | Five-year Silver CarePlan with annual standard calibration, Instrument covered: 9144, FIELD METROLOGY WELL | |
| SCP9144-STD | One-year Silver CarePlan with annual standard calibration, Instrument covered: 9144, FIELD METROLOGY WELL | |
| 9144-X-P | 現場計量井，50 °C 到 660 °C，w/9144-INSX，w/電子工藝 | |
| 以上型號中的 X 將替換為 A、B、C、D、E 或 F，代表適當的嵌板。 | ||
| 配件 | 描述 | |
| 9144-INSA | A 型插塊，英制各種插孔 | |
| 9144-INSB | B 型插塊，英制對稱插孔 | |
| 9144-INSC | C 型插塊，0.25 英寸插孔 | |
| 9144-INSD | D 型插塊，公制對稱插孔 | |
| 9144-INSE | E 型插塊，公制各種插孔和0.25 英寸插孔 | |
| 9144-INSF | F 型插塊，公制對稱插孔和0.25 英寸插孔 | |
| 9144-INSZ | Z 型插孔，空白插塊 | |
| G3P9144P-STD | Three-year Gold CarePlan with annual standard calibration, Instrument covered: 9144-P, FIELD METROLOGY WELL | |
| G5P9144P-STD | Five-year Gold CarePlan with annual standard calibration, Instrument covered: 9144-P, FIELD METROLOGY WELL | |
| GCP9144P-STD | One-year Gold CarePlan with annual standard calibration, Instrument covered: 9144-P, FIELD METROLOGY WELL | |
| S3P9144P-STD | Three-year Silver CarePlan with annual standard calibration, Instrument covered: 9144-P, FIELD METROLOGY WELL | |
| S5P9144P-STD | Five-year Silver CarePlan with annual standard calibration, Instrument covered: 9144-P, FIELD METROLOGY WELL | |
| SCP9144P-STD | One-year Silver CarePlan with annual standard calibration, Instrument covered: 9144-P, FIELD METROLOGY WELL | |
